TZ08E-TZ18E

Electric Mini Excavators - Advanced Zero-Emission Construction Solutions

Are you looking for eco-friendly development hardware that conveys uncommon execution whereas diminishing operational costs? Our Electric mini excavators represent the future of sustainable construction machinery. Manufactured by Taiyuan Heavy Machinery Group Co., Ltd., these imaginative machines combine cutting-edge electric innovation with demonstrated designing fabulousness. With models extending from TZ08E to TZ18E, our electric excavators offer zero outflows, quick reaction times, and altogether lower working costs compared to conventional fuel-powered alternatives.

Parameters

Specification	TZ08E	TZ18E
Total Weight (kg)	1,075	1,965
Bucket Capacity (m³)	0.025	0.050
Motor Power (KW/rpm)	7.4/3225	10/2000
Battery Capacity	11.8kwh	21.5kwh
Charging Time	2 hours (Fast charge) 4 hours (Slow charge)	2 hours (Fast charge) 4 hours (Slow charge)
Battery Endurance	4-6 hours	4-6 hours
Rated flow of main pump	2×11 L/min	64 L/min
Pressure-main valve	16 MPa	21.6 MPa
Pressure-travel system	16 MPa	21.6 MPa
Pressure-swing system	11 MPa	11 MPa
Pressure-pilot system	3.9 MPa	3.9 MPa
Travel speed(high/low)	3.2 km/1.5 h	3.8 km/2.4 h
Swing speed	8.2 r/min	9.1 r/min
Gradeability	30。	30。
Ground pressure	28 kPa	32.5 kPa
Bucket diging force	9.9 kN	14.2 kN
Arm digging force	4.5 kN	8.5 kN
Max.traction force	8.8 kN	19.5 kN

How Our Electric Mini Excavators Help You Gain Benefits

Cost Reduction

You'll involvement drastically lower operational costs with our electric models. Quick charging inside fair 2 hours implies negligible downtime, whereas killing fuel costs diminishes your day by day working budget by up to 60%.

Environmental Compliance

Meeting strict emanation prerequisites gets to be easy. Our zero-emission innovation makes a difference you comply with natural controls and qualify for green development ventures in urban regions and touchy environments.

Enhanced Productivity

The high-power lasting magnet engine conveys moment torque and steady execution. You'll appreciate quick reaction times and smooth operation all through amplified work sessions.

Operational Flexibility

Low commotion operation permits you to work in private zones, clinics, and noise-sensitive zones without confinements. This opens up modern venture openings already inaccessible with customary excavators.

Electric Mini Excavators Advantages

Pure Electric Power System

Our machines highlight progressed battery innovation matched with high-performance changeless magnet engines. This combination guarantees long-term nonstop operation whereas keeping up reliable control conveyance all through your workday.

Superior Safety Features

Three control frameworks from famous brands ensure solid operation. The coordinates security frameworks ensure both administrator and gear, giving you peace of intellect amid requesting development tasks.

Advanced Hydraulic Technology

You'll advantage from our touchy stacking water powered framework that gives extraordinary operability. The responsive controls permit exact developments, making sensitive work less demanding and more efficient.

Modern Operator Experience

The modern era cab highlights touch screen controls, transport control frameworks, and coordinates radio. These consolation upgrades decrease administrator weakness and increment efficiency amid long shifts.

Working Scene Applications

Urban Construction Projects

Perfect for city center advancements where clamor limitations and outflow controls are required. Your group can work amplified hours without exasperating adjacent inhabitants or businesses.

Landscaping Operations

Ideal for parks, golf courses, and private arranging where natural assurance is fundamental. The compact plan permits get to to tight spaces whereas keeping up zero natural impact.

Pipeline and Utility Work

Essential for underground utility establishment where accuracy and natural compliance are basic. The responsive controls make exact trenching and pipe laying effortless.

Agricultural Applications

Excellent for farmland water conservancy ventures, water system framework establishment, and agrarian framework improvement. The eco-friendly operation secures soil and water quality.

Why Choose Us

Industry Pioneer Heritage

As China's to begin with autonomously outlined overwhelming apparatus producer, we bring over 70 a long time of building brilliance to each machine. Our demonstrated track record incorporates 40,000+ gear conveyances worldwide.

Global Recognition

Our items serve clients in more than 70 nations, illustrating worldwide quality measures and unwavering quality you can believe for your projects.

Innovation Leadership

Backed by national key laboratories and 32 innovation platforms, we continuously advance electric mini excavators technology to meet evolving industry needs.

Manufacturing Excellence

Our world-class "Lighthouse Network" shrewdly fabricating offices guarantee reliable quality and progressed generation methods in each machine.

Certificates

Our fabricating forms and items meet universal quality guidelines. All important certifications are accessible upon ask and shift by goal showcase requirements.

Packaging & Shipping

Secure Packaging

Each excavator gets defensive bundling outlined for universal shipping. Specialized crating guarantees your gear arrives in idealize condition notwithstanding of destination.

Global Logistics Network

We facilitate around the world shipping through set up coordinations accomplices. Our experienced group handles all send out documentation and traditions necessities for smooth delivery.

Delivery Timeline

Standard conveyance times shift by goal and current generation plan. Contact our deals group for particular conveyance gauges based on your area and requirements.

FAQ

Q: How long does the battery last during operation?

A: Our product operate 6-9 hours on a single charge, depending on working conditions and model selection.

Q: What maintenance is required compared to diesel models?

A: Electric models require significantly less maintenance - no oil changes, fewer moving parts, and reduced wear components mean lower maintenance costs.

Q: Can these machines handle heavy-duty construction work?

A: Absolutely! The electric motors provide instant torque and consistent power, often outperforming comparable diesel models in demanding applications.

Q: What charging infrastructure do I need?

A: Standard industrial electrical supply is sufficient. Our machines charge fully within 2 hours using conventional power connections.

Q: Are replacement parts readily available globally?

A: Yes, we maintain parts distribution networks in all major markets with local service support available.
